DOBOT MAGICIAN ARDUINO AI KIT - Arduino A.I. Kit for Magician robotic arms
ENTRY-LEVEL LEARNING SET FOR ARTIFICIAL INTELLIGENCE
for Dobot Magician BASIC, EDU, and LITE robotic arms
An entry-level A.I. tutorial kit that includes a DFRduino Mega 2560 control panel, LED indicator, joystick, switch button.
Plenty of training courses are available for children to quickly get a feel for programming and controlling the robot, the basics of AI, and then understand, support and cultivate open source creative culture!
Discover the link between machine intelligence and humans:
The electronic modules include a programmable control unit, various sensors, voice and image recognition. The lights and DOBOT Magician can be controlled by joystick buttons and voice commands, making it easy for children to explore artificial intelligence./span>
Fun electronic manufacturing through project-based learning:
Students can learn step-by-step about interactive devices, different sensors, how to operate controls and feedback from devices with a series of teaching demos. Flexible learning and playful experimentation with lots of fun!
Smartly Play technology on an open source electronic platform:
The open source platform, focused on studies, is compatible with Mixly, the peripheral sensors associated with Arduino, and supports secondary development, controlled by Arduino.
Supporting creative, imaginative thinking:
By programming a DOBOT in a remote controlled way, children can get an insight into how the circuits work, as well as the programming process itself and make their ideas easier to realise.
Parameters
DFRduino mega 2560 V3
| Microcontroller | ATmega2560 |
| Operation Voltage | 5V |
| Input Voltage (recommended) | 7V - 12V |
| Input Voltage (full range) | 6V - 20V |
| Digital I/O pins | 54 (which from 15db can be used as PWM output) |
| Analog input I/O pins | 16 |
| DC Curent per I/O pin | 50 mA |
| DC Current on 3.3V pin | 50 mA |
| Flash memory | 256 KB from which 4KB is used by bootloader |
| SRAM | 8 KB |
| EEPROM | 4 KB |
| Clock speed | 16MHz |
Pixy CUMcam5
| Processor | NXP LPC4330, 204MHz, két-magos |
| Image recognizer | Omnivision OV9715, 1/4", 1280x800 |
| Lens | standard M12 |
| Power | 140 mA |
| Input voltage | USB input (5V) not controlled (6V - 10V) |
| RAM | 264KB |
| Flash | 1M byte |
| Available outputs | UART serial, SPI, I2C, USB, digital, analog |
| Size | 2.1" x 1.75" x 1.4" |
Digital button module
| Color of buttons | red,green,blue |
| Voltage | 3.3V - 5V |
| Data type | Digital |
| Size | 22mm x 30mm |
LED module
| Colors | Red, green, blue |
| Light intensity | 2500mcd - 3300mcd Highlight output |
| Voltage | 3.3V - 5V |
| wavelength | 520nm - 530nm |
| angle | 80° - 110° |
| Size | 30mm x 20mm |
| Weight | 5g |
Content of the package
- 1 pcs DfRduino mega2560 V3 (compatible Arduino mega 2560)
- 1 pcs Pixy CUMcam5
- 1 pcs Digital button module
- 1 pcs LED module
- 1 pcs joystick
- Connection cable
